Our marquee covers use rip-stop technology making them tear resistant and long-life. There are many types of marquee PVC but we make sure only to use high-quality Duracoretex™ material. Covers are 100% waterproof with high-frequency welded seams, fire retardant to to BS5438 & BS7837 and UV stabilised.
All sides are included. The marquee sides all include zips in the middle and can be opened. There are enough sides for windows to go down the length of the marquee and enough walls to cover the ends. They are all in 3m wide x 2.3m tall interchangeable sections.
| Roof material | 560gsm PVC |
|---|
| Sides material | 560gsm PVC |
|---|
|
| Tearing-strength | 1666N |
|---|
Seams | High-frequency welded & reinforced | | Flame retardant | Yes to BS5438 & BS7837 |
|---|
| UV stabilised | Yes |
|---|
| Rain-skirt | Yes |
|---|
| Wind-stop Velcro sealed sides | Yes |
|---|
| Waterproof | 100% waterproof |
|---|
Dimensions
| Size | 9x18m |
|---|
| Width | 9.00m |
|---|
| Length | 18.00m |
|---|
| Height at top of leg | 2.30m |
|---|
| Height at apex | 5.10m |
|---|
| Entrance dimensions | Approx 3.00m x 2.30m |
|---|
Assembly
Assembly instructions can be downloaded here. Alternatively give us a call on 01306 87 67 67 and we’ll email you a copy.
| Minimum number of people to erect | 2 |
|---|
| Ideal number of people to erect | 2-3 |
|---|
|
| Time to erect | 3-4 hours on average |
|---|
Delivery
We will contact you within 1 working day (usually immediately) to confirm the delivery day (usually 2-3 working days). If you have any preference on delivery day please let us know and we will happily arrange delivery accordingly.
Your marquee will arrive either on a pallet or in a van. Drivers are always requested to call 1 hour ahead of delivery.
Included in the delivery
- Framework including all connectors and poles
- Roof cover
- Side covers
- Bolts
- Foot plates
- Leg spikes
- Stakes
- Stake bars
- Webbing/ratchet straps
- Tent pegs
- Any optional extras
- Assembly instructions
Same day collection from Unit 15, Havenbury Industrial Estate, Station Road, Dorking, Surrey, RH4 1ES is available. Just let us know when you intend to arrive so the marquee can be ready and waiting for you.
Frequently Asked Questions
What are the key specifications of this marquee?
The marquee measures 9 m (width) × 18 m (length), with a leg height of approximately 2.30 m and an apex height of around 5.10 m. It features strong aluminium keder channel legs (84 mm × 48 mm), 102 mm diameter aluminium centre poles, and 560 gsm Duracoretex commercial-grade PVC fabric. Double-headed stakes (90 cm × 25 mm) are used for secure anchoring.
How many guests can it accommodate?
It comfortably seats 60–180 people and can hold up to 240 people standing—ideal for dancing or mingling.
Can the marquee be extended or configured differently?
Yes, it’s modular. While it’s designed as a 9 m × 18 m marquee, it can also be erected as 9 m × 12 m, or further extended to 9 m × 24 m, 9 m × 30 m, etc.
Is this suitable for use on hard standing?
Absolutely. The marquee can be installed on hard surfaces such as concrete or tarmac—stake bars can be drilled and bolted in for a solid fix.
Is it waterproof and durable?
The PVC covering is made from high-frequency welded, rip-stop Duracoretex, making it fully waterproof and highly robust—perfect for heavy-duty, repeated use.
What if I need replacement parts or advice?
Replacement parts are readily available, and experienced customer service staff are on hand for support.
Can it be used in winter or extreme conditions?
Yes, though it’s advisable to take extra precautions during snow or severe weather. Additional measures such as snow-clearance plans or enhanced anchoring should be considered.
Does it include all of the ropes and stakes?
Yes, all of the stakes, stake bars ratchets straps and webbing are included with the marquee.
Are the sides included with the marquee?
Yes, all of the sides are included with enough windows to go down either side and walls at the end. All sides are unzippable and interchangeable.
Spare Parts
Spare parts are stocked for all of our marquees. Parts can be purchased and delivered usually within 2-3 working days. It is important to be able to maintain your marquee and repair it in case it becomes damaged. Any part including connectors, poles, braces, walls and even the roof can be replaced.
PVC can also be repaired using a high strength vinyl cement. We can supply the vinyl cement with pre-cut patches to repair the PVC.
Finance
Finance available! Finance available on orders over £500. Our finance partners currently offer finance to business customers only.
Manufacturer’s Warranty Details
DIY Marquees 12-month Warranty
All DIY Marquees products are covered by a manufacturer’s warranty against any defects in workmanship or materials for a period of 12 months from the delivery date. All units should be inspected upon arrival, and defects or shortages reported immediately.
This warranty is limited to normal wear and tear.
Full warranty details
Spare Parts Guarantee
We stock all spare metal componants including poles, connectors, braces as well as all covers including replacement roofs, side panels and leg covers.
The person who bought our first marquee can still get spare parts and we plan to keep it that way. Delivery is typically overnight for spares.
